Hitec HS-5646WP High Voltage Waterproof Metal Gear Digital Servo

This is the Hitec HS-5646WP High Voltage Waterproof Metal Gear Digital Servo. Hitec waterproof servos have what it takes to keep your radio control vehicle, airplane or robot watertight! With high torque, dual ball bearings and metal gears, these digital waterproof servos feature the industry’s first IP67* rating, ranking them among the most durable and reliable servos for wet conditions. Whether you are manning your power boat, bashing in the mud, directing your underwater robot, or water landing your 25% plane, the HS-5646WP will keep your mind at ease.

Features:

• Industry first, true water proof servo (IP67 Industrial Standard Approved)
• Patent Acquired Water proof design
• High Torque version
• 7.4V 2 cell LiPo & 6 cell NiMH compatible
• Durable metal gears with ball bearing
• Programmable digital amplifier with MOSFET drive
• Use with
• 1/10, 1/8, 1/5 and 1/4 scale cars
• EP & GP boats

Specifications:
Size Category: Standard
Type: Digital
Application: Boats, mud bashers, underwater robots, and water-landing planes up to 25% scale
Torque: 157 oz-in (11.3 kg-cm) @ 6.0V; 179 oz-in (12.9 kg-cm) @ 7.4V
Speed: 0.20 sec/60° @ 6.0V; 0.18 sec/60° @ 7.4V
Length: 1.65 in (42mm)
Width: 0.83 in (21mm)
Height: 1.57 in (40mm)
Weight: 2.15 oz (61 g)
Bushing Or Bearing: Bearing
Bearing: Dual
Motor Type: 3-pole ferrite
Gear Type: Metal
Voltage: 6.0V-7.4V

This product was added to our catalog on July 23, 2013
